Ci Detail Elements
This tool is only available in New Zealand, and in Australia for Select Annual customers.
Detail Elements take the work out of detailing with a huge set of smart parametric 2D objects ready to be dragged and dropped. It saves hours from the documentation process by dynamically editing them, and remove the mundane and boring aspects of detailing.
Core Elements
- Insulation, Lining, Steel Sections and Timber members Floors
- Floorboards and Floor Framing
Walls
- Brick and Block sections, wall frames and boards, individual blocks
Roofs & Ceilings
- Fascia Boards, Gutters, Ridge Caps, Cladding, Tiles, Ceiling Battens and a variety of Trusses Doors & Windows
- Door and Window Frames and Glass
Fastenings
- Bolts, Nails, Screws, Nail Plates, Brackets and Fixings
Reinforcing
- Reinforced Beams, Cages, Meshes and Rods
Symbols
- Break lines, Cylinder Break Lines, Roof Pitch angle symbols and Weld Symbols
This tool is only available in New Zealand, and in Australia for Select Annual customers.
Premium Package
Access to 12 Tools*
Exclusive free Archicad objects and resources
Priority support: we use an online support ticket system to manage your enquiries, and aim to respond to you within 2 business days – if not before.
Month-by-month plan AUD $80 /month (more currencies available)
or Annual billing AUD $800 /year
